Y47L Air vents 1
Automatic air vent
  • Working temperature range (peaks): -20 (no frost)–110 °C
  • Working temperature range: 0 (no frost)–95 °C
  • Max working pressure: 10 bar
  • Suitable fluids: water for thermal systems, glycol solutions (max 30%)
  • Connections: threaded connections ISO 228-1
  • Product codes
  • Description
  • Documentation
  • Accessories
  • Alternative products
Product codes
Item code Size Download the 3D file
Y47010000L G 3/8 M 10 100
Y47015000L G 1/2 M 10 100
Y47020000L G 3/4 M 10 100
Y47025000L G 1 M 10 100
The Barberi® automatic air vents allow to remove air from the installations without manual operations. They are normally installed in heating systems, central heating rooms, heating generators (wall-mounted boilers, solid fuel generators, heat pumps). Thanks to the air removal they allow a longer system life without component oxidation, a higher thermal efficiency, a better working and safety of pumps. For a better air removal, the valves must be installed in the upper parts of the systems and in all areas where there is a risk of air bubble forming (reverse syphons, manifolds, storages, boilers).
