02G.DN20
02G.DN20 Distribution and regulating groups DN 20 1
02G.DN20
Thermostatic group DN 20
  • Max working temperature: 90 °C
  • Max working pressure: 10 bar
  • Threaded connections: ISO 228-1
  • Pump: Grundfos UPM3 AUTO 25-70 130; Wilo Para 15/7-50/SC 130; Grundfos UPSO 15-65 130 (Extra EU)
  • Thermostatic mixing valve adjustment range: 30–60 °C and 25–50 °C
  • Suitable fluids: water, glycol solutions (max 30%)
  • Temperature gauge scale: 0–120 °C
  • Product codes
  • Description
  • Documentation
  • Accessories
  • Alternative products
  • Spare parts
Product codes
Item code Size Kv Manufacturer Pump °C Download the 3D file
02G02000P G 1 M - (G 1 M+G 3/4 F) 3,5 1 Wilo Para 15-130/7-50/SC-9 30–60
02G02000L G 1 M - (G 1 M+G 3/4 F) 3,5 1 Grundfos UPM3 AUTO 15-70 130 30–60
02G02000F G 1 M - (G 1 M+G 3/4 F) 3,5 1 Grundfos (Extra EU) UPSO 15-65 130 30–60
02G02000X G 1 M - (G 1 M+G 3/4 F) 3,5 1 SenzaPompa WITHOUT PUMP 30–60
02G02000PE G 1 M - (G 1 M+G 3/4 F) 3,5 1 Wilo Para 15-130/7-50/SC-9 25–50
02G02000LE G 1 M - (G 1 M+G 3/4 F) 3,5 1 Grundfos UPM3 AUTO 15-70 130 25–50
02G02000FE G 1 M - (G 1 M+G 3/4 F) 3,5 1 Grundfos (Extra EU) UPSO 15-65 130 25–50
02G02000XE G 1 M - (G 1 M+G 3/4 F) 3,5 1 SenzaPompa WITHOUT PUMP 25–50
Description
Preassembled pump group for fixed point regulation and circulation of mixed fluid. Allows the circulation of the thermal fluid, coming from the primary circuit, by keeping the temperature at a pre-set value (fixed point) through the help of a mixing valve with thermostatic element. It is used in heating systems in general and radiant panel systems. The group is composed of a pump, flow/return shut-off valves, thermostatic mixing valve, flow/return temperature gauges, anti-thermosiphon check valve, thermal insulation. In this group, the differential by-pass can be installed only externally. The group is reversible (flow line can be exchanged with the return line). Male and female thread on system side connections.
